Font`N-Aire Platinum 2HP Single Phase Floating Fountains

The unique center discharge pump design of the CENTRIFUGAL PUMP DISPLAY FOUNTAIN ensures the vertical alignment of both the submersible motor's shaft and the discharge. Consequently, this design characteristic concentrates the entire weight of the fountain at the center of the float. This not only streamlines the installation and removal processes from the float but also eliminates the need for specialized mounting brackets or hardware.

Moreover, our centrifugal pump design excels in producing high pressure, allowing for the creation of impressive heights and displays. Notably, this performance is achieved with significantly lower horsepower requirements compared to alternative fountain equipment. It is crucial to emphasize that the primary purpose of this fountain is purely aesthetic. This distinction arises from the fact that the volume of water propelled into the air is not substantial enough to classify it as an aerating device, a determination made through oxygen transfer testing and strict adherence to Air-O-Lator's standards.

Details

• FLOAT – constructed of rugged polyethylene molded plastic with UV inhibitors and filled with non-hygroscopic pressure molded polystyrene foam.
• POWER DRIVE ASSEMBLY – mounting structure (drive structure assembly), pump/propeller, nozzle, and motor.
• ELECTRICAL SERVICE CABLE ASSEMBLY – Consisting of a standard 100’ length of AWG# 12/4 submersible cable and a submersible quick disconnect connector, which conveniently plugs into the fountain.
• CONTROLS – These controls feature a 24-hour time clock with multiple off/on trippers, a Franklin Electric start and run QD capacitor box, and an inline ELCI ground fault protector. Additionally, all of these components come prewired and mounted on a 16” x 14” plate. It is noteworthy that Air-O-Lator exclusively employs the Franklin Electric 600M submersible motor for all fountain lines. This water-cooled and lubricated motor is purposefully designed for lake and pond fountain applications, ensuring environmental safety.

Features

• No seals or bearings to maintain.
• High-speed, foul-resistant propellers or impellers, provide high shear water spraying action. No lazy sprays, bubbles, or slow boil of water.
• One-piece square flotation for stability to minimize any oscillation that can occur with round floats.
• Watertight, removable, 100’ power cable is standard. Additional cable lengths are available in 50’ increments.
• ETL listed (ANSI/UL508) control panel with time clock (adjustable in 15-minute increments), and Equipment Leakage Circuit Interrupter (ELCI) (US only).
• Exclusive Franklin Electric Sand Fighter submersible motor, which implements the use of a silicon carbide mechanical sealing system.
• 3-year Limited Warranty
